MODEL:TZ-206

TOA TZ-206 Column Speaker (Black/White)

Categories: ,

Specifications:

  • Enclosure Sealed Type
  • Rated Input 20 W
  • Rated Impedance 100 V line: 500 Ω (20 W), 1 kΩ (10 W), 2 kΩ (5 W), 4 kΩ (2.5 W) 70 V line: 500 Ω (10 W), 1 kΩ (5 W), 2 kΩ (2.5 W), 4 kΩ (1.3 W)
  • Sensitivity 90 dB (1 W, 1 m)
  • Frequency Response 150 Hz – 16,000 Hz
  • Speaker Component 10 cm cone-type × 2
  • Input Terminal Push-In terminal
  • Finish Enclosure: HIPS, black, paint
  • Punched Net: Surface-tread steel plate, black, paint
  • Speaker Bracket: Aluminum die-cast, black, paint
  • Joint Bracket, Wall Bracket: Steel plate, t1.6, black, paint
  • Dimensions 135 (W) × 250 (H) × 128 (D) mm
  • Weight 1.9 kg (unit only)
  • Accessory Speaker Bracket x 1, Joint Bracket x 1, Wall Bracket x 1, Fixing Bolt (M5 x 60) x 1, Hexagon Bolt (M6 x 12) (with plain washer and spring washer) x 2, Machine Screw (M5 x 20) (with plain washer and spring washer) x 2, Hexagon Bolt (M8x 15) x 1
  • Option Speaker Stand: ST-16A
