Feature:
- Channel Amplifier: Mono
- Parallel Looping: N/A
- Bluetooth: Yes, Enable you to connect wireless to your telecommunication device such as smartphone, pad, notes, etc
- USB: Yes
- Tuner FM: Yes
- Zone Selector: 4-zone selector
- Mic Phantom Power (48V): Yes, MIC-1 equipped with DC+18V phantom power (selectable)
- Mic Priority: Yes, MIC-1 equipped with mic priority feature (selectable)
- XLR/Phono Jack Input Per Channel: 7-channel (MIC x3, LINE 1-5), mic input at back panel
- XLR/ Phono Jack Output Per Channel: 1-channel LINE output
- Input Gain Control: Master volume, bass and treble control
- Parallel/Mono Selection Switch: N/A
- Speaker Output: 8Ω, 100V
- Flight Case Mounted: Yes. Standard 19″ rack
- Height (3U,2U,1U): 2U
- Circuit Protection: Short circuit, over load, over temperature, AC/DC fuse
Specification:
- Output Power: 240 Watt
- Power Supply: AC 230V, 50-60HZ, DC 24V
- Speaker Output: 8Ω, 4x100V
- Line Output: RCA signal output
- Record Output: N/A
- Frequency Response: 100Hz-16kHz ± 3dB
- Input Sensitivity & Impedance: XLR (balanced): Channel 1 (MIC 1), -50dBV @ 5kΩ 1/4″ phone jack (balanced): Channel 2-3 (MIC 2-3), -50dBV @ 5kΩ 1/4″ phone jack (unbalanced): Channel 4-5 (LINE 2-3), -10dBV Channel 6 (LINE 4) or LINE 4 (RCA), -10dBV Channel 7 (LINE 5) or LINE 5 (RCA), -10dBV
- Mute Priority: MIC 1 (selectable)
- Voice Priority Mute: MIC 1 > VOX Mic Priority (-40dB LINE)
- Phantom Power Adjustable (48V): MIC 1 equipped with DC +20V phantom power (selectable)
- Tone Control: Bass: 100Hz ± 10dB, Treble 10kHz ± 10db
- Total Harmonic Distortion: <2% @ 1kHz, rated power
- Signal To Noise Ratio: MIC 1-3 @ 70dB, LINE 2-5 @ 80dB
- Indicator: Power On, Level
- AC Power Consumption: 617Watts
- DC Power Consumption: 15A
- Product Dimension (WxHxD): 433mm x 89mm x 320mm
- Weight: 11.5kg
